InGaAs Narrowband Receivers for 60 GHz cellular, Ka Q U V bands
| Model |
Application |
Specification
|
Package Option |
|
LMDS or cellular band |
Microwave bands for RF over fiber |
Typ. Amp. Power Gain |
Module |
Lab Buddy |
| DSC-R406 - PIN Photoreceiver with FWHM Bandwidth of 20 - 32 GHz |
28 GHz |
Ka,K |
20 dB |
✔ |
✔ |
| DSC-R407 - PIN Photoreceiver with FWHM Bandwidth of 36 - 44 GHz |
39 GHz |
Q,U |
18 dB |
✔ |
✔ |
| DSC-R408 - PIN Photoreceiver with FWHM Bandwidth of 42 - 60 GHz |
60 GHz |
Q,U,V |
20 dB |
✔ |
✔ |
Description:
Designed for microwave RF over fiber applications, these high-gain fiber-pigtailed modules are designed to support 28, 39 and 60 GHz applications. Compact, hermetically sealed module can be directly connected to microwave antenna for high data rate wireless transmission to mobile or fixed receivers.
Frequency Response Curves
Salient Features:
- R406 offers 20 dB gain for 28 GHz LMDS, K and Ka transmission over fiber
- R407 offers 18 dB gain for 39 GHz LMDS, Ka and Q bands
- R408 offers 20 dB gain for Q, U, V or W bands, 60 GHz cellular
- Low electrical back reflection
- Small size, hermetically sealed
- Meets industry GR-468 reliability Standards
Applications:
- Hybrid fiber/wireless systems
- Distribution of microwave RF carriers
- Optical phased-array radar
- 40 Gb clock recovery
Available Models:
- DSC-R406 - 20-32 GHz High Gain Narrowband Optical Receivers
- DSC-R407 - 36-44 GHz High Gain Narrowband Optical Receivers
- DSC-R408 - 42-60 GHz High Gain Narrowband Optical Receivers
