Description:

The DSC10H and DSC20H are hermetically sealed, high reliability, low harmonic distortion photodiode modules designed for high optical power applications. The devices are well suited for receiver applications with optical preamplification and have a small physical footprint.

DSC10H and DSC20H High Optical Power Handling InGaAs Photodiodes to 50 GHz

Fig: DSC-10H, DSC-20H High Optical Power Handling InGaAs Photodiodes to 50 GHz

Salient Features:

High Optical Power Delivers up to 500 mV_pp Output
Lowest PDL (typical 0.05 dB)
Useable spectral wavelength range of 1064-1650 nm
Low Group Delay
Low Harmonic Distortion
Small Footprint & High Reliability
Bellcore GR-468 Qualified
One device for multiple wavelengths reduces operational & inventory costs

Applications:

Optically Amplified Systems
RZ, NRZ, Super FEC Formats to 43 Gb/s
Low Distortion, High Dynamic Range Analog RF Links over Fiber
Rapid Doppler-Shift LIDAR Measurements
Coherent Lightwave Systems
Ideal Front-End O/E Converter for Test Instruments

Frequency Response Curves

Available Models:

DSC10H - 42+ GHz High Optical Power Handling Photodiodes
DSC20H - 32+ GHz High Optical Power Handling Photodiodes
