Description:
These low harmonic distortion, high speed photodiodes are hermetically sealed, and are designed for high optical power applications with minimum bandwidth of 6 GHz. These devices employ custom optical beam shaping techniques and are well suited for applications requiring highly linear operation such as antenna remoting, RF-over-fiber signal distribution, and photonic microwave oscillators. These photodiode modules are available in either a K-connector package or a miniature surface mount package with CPW (coplanar waveguide) RF output, and utilizes Discovery's high-reliability InGaAs photodiode technology.
Fig1: DSC100_100S InGaAs Photodiodes with Lab Buddy
Fig2: Frequency Response Curve for
High Optical Power Handling, Highly Linear Photodiodes
Salient Features:
- High Current Handling (> 30 mA)
- Highly Linear Operation (OIP2 > +55 dBm, OIP3 > +45 dBm)
- Lowest PDL (typical 0.05 dB)
- Useable spectral wavelength range of 800-1650 nm
- K-connector or surface mount package options
- Low Group Delay
- High Reliability
- One device for multiple wavelengths reduces operational & inventory costs
Applications:
- High Dynamic Range, Analog RF Links for Antenna Remoting
- RF-over-Fiber signal distribution for GPS, GSM, CDMA, WiMax, LTE, etc.
- Low-Phase Noise Photonic Microwave Oscillators
- Photonic Analog-to-Digital Converters
- Coherent Lightwave Systems having high coherent gain
- Ideal Front-End O/E Converter for Test Instruments
Available Models:
- DSC100 - High Optical Power Handling Photodiodes to 6 GHz
- DSC100S - High Optical Power Handling Photodiodes to 6 GHz
